Description
[rt_button_style title=”CATALOG” link=”url:https://www.saxco.com.my/wp-content/uploads/2018/01/DH-HAC-HDBW2221F.pdf|||”]
| Camera | ||
|---|---|---|
| Image Sensor | 1/2,7″ 2.1 Megapixel CMOS | |
| Effective Pixels | 1928(H)x1088(V) | |
| Electronic Shutter | 1/3s~1/100,000s | |
| Video Frame Rate | 25/30/50/60fps@720P;25/30fps@1080P | |
| Synchronization | Internal | |
| Min.Illumination | 0.03Lux/F2.0, 0Lux IR on | |
| Video Output | 1-channel BNC HDCVI high definition video output/CVBS standard definition video output SD Tester out |
|
| Camera Features | ||
| Max.IR LEDs Length | 20m, Smart IR | |
| Day/Night | Auto(ICR)/Color/B/W | |
| Backlight Compensation | 120dB True WDR | |
| Noise Reduction | 2D/3D | |
| OSD Menu | Multi-language | |
| Lens | ||
| Focal Length | 3.6mm (2.8mm, 6mm optional) | |
| Angle of View | H: 90º(115.6º/59.4º) | |
| Mount Type | M12 | |
| General | ||
| Power Supply | DC12V±25% | |
| Power Consumption | Max 3.5W | |
| Working Environment | -30°C~ 60°C / Less than 95%RH (no condensation) | |
| Transmission Distance | Over 500m via 75-3 coaxial cable | |
| Ingress Protection | IP67 & IK10 | |
| Dimensions(W x D x H) | Φ106.3mm×50.3mm | |
| Weight | 0.3kg | |
| Material | Metal | |
| Others | Build-in MIC | |
