| Camera | ||
|---|---|---|
| Image Sensor | 1/2.8″ CMOS | |
| Effective Pixels | 1937(H)x1097(V), 2.1MP | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | PAL: 1/4s~1/100000s NTSC: 1/3s~1/100000s |
|
| Minimum Illumination | 0.005Lux/F1.3, 30IRE, 0Lux IR on | |
| S/N Ratio | More than 65dB | |
| IR Distance | Up to 30m (98feet) | |
| IR on/Off Control | Auto/Manual | |
| IR LEDs | 2 | |
| Lens | ||
| Lens Type | Motorized lens / Fixed iris | |
| Mount Type | Board-in | |
| Focal Length | 2.7-13.5mm | |
| Max Aperture | F1.3 | |
| Angle of View | H: 102°~29° | |
| Focus Control | Auto/Manual | |
| Close Focus Distance | 200mm 7.87″ |
|
| Pan/Tilt/Rotation | ||
| Pan/Tilt/Rotation | Pan: 0° ~ 355° Tilt: 0° ~ 75° Rotation: 0° ~ 355° |
|
| Video | ||
| Resolution | 1080P (1920×1080) | |
| Frame Rate | 25/30fps@1080P, 25/30fps@720P | |
| Video Output | 1-channel BNC high definition video output / CVBS video output (Can switch) |
|
| Day/Night | Auto (ICR)/ Manual | |
| OSD Menu | Multi-Language | |
| BLC Mode | BLC/HLC/WDR | |
| WDR | 120dB | |
| Gain Control | AGC | |
| Noise Reduction | 2D/3D | |
| White Balance | Auto/Manual | |
| Smart IR | Auto/Manual | |
| Certifications | ||
| Certifications | CE: (EN55032, EN55024, EN50130-4) FCC: (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL: (UL60950-1 CAN/CSA C22.2 No.60950-1) |
|
| Interface | ||
| Audio Interface | N/A | |
| Eelectrical | ||
| Power Supply | AC24V±25%/DC 12V±25% | |
| Power Consumption | Max 8W (12V DC, IR on) | |
| Environmental | ||
| Operating Conditions | -40°C ~ 60°C (-40°F ~ 140°F) / Less than 90% RH * Start up should be done at above -40°C (-40°F) |
|
| Storage Conditions | -40°C ~ 60°C (-40°F ~ 140°F) / Less than 90% RH | |
| Ingress Protection & Vandal Resistance | IP67, IK10 | |
| Construction | ||
| Casing | Aluminium | |
| Dimensions | Φ122mm×88.9mm (Φ4.8″×3.5″) | |
| Net Weight | 0.48KG (1.06Ib) | |
| Gross Weight | 0.63KG (1.39Ib) | |
