Description
| Camera | ||
|---|---|---|
| Image Sensor | Three 1/2.8″ 2MP STARVISTM CMOS | |
| Effective Pixels(Panorama) | 4K (3840×832)/4M(2560×554) | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | PAL: 1/4s~1/100,000s NTSC: 1/3s~1/100,000s |
|
| Minimum Illumination | 0.005Lux/F1.8 (Color), 30IRE, 0Lux/F1.8(IR on) | |
| S/N Ratio | More than 65dB | |
| IR Distance | 20m | |
| IR On/Off Control | Auto (ICR)/Color/B/W | |
| IR LEDs | 6 | |
| Lens | ||
| Lens Type | Fixed lens/ Fixed iris | |
| Mount Type | Board-in | |
| Focal Length | 3.6mm | |
| Max Aperture | F1.8 | |
| Angle of View | H: 180° | |
| Focus Control | N/A | |
| Close Focus Distance | 500mm 19.7″ |
|
| Pan/Tilt/Rotation | ||
| Pan/Tilt/Rotation | Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotation: 0° ~ 360° |
|
| Video | ||
| Resolution | 4K (3840×2160)/4MP(2560×1440) | |
| Frame Rate | PAL:3840×2160@12.5fps,2560×1440@25fps; NTSC:3840×2160@15fps,2560×1440@25fps; |
|
| Video Output | 1-channel BNC HDCVI panoramic video output & 3-channels BNC 2MP HDCVI video output |
|
| Day/Night | Auto (Electronic)/Manual | |
| OSD Menu | Multi-language | |
| BLC Mode | BLC/ HLC/ WDR | |
| WDR | 120dB | |
| Gain Control | AGC | |
| Noise Reduction | 2D/3D | |
| White Balance | Auto/ Manual | |
| Smart IR | Auto/ Manual | |
| Certifications | ||
| Certifications | CE: (EN55032, EN55024, EN50130-4) FCC: (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL: (UL60950-1 CAN/CSA C22.2 No.60950-1) |
|
| Interface | ||
| Alarm I/O | 2/1 | |
| Audio Interface | 1-channel audio in(JACK) | |
| Test interface | 1-channel 2-pin CVBS video output | |
| Upgrade Interface | 1-channel 4-pin USB input | |
| Code switcher | 1 physical code switch (switch the preset video source) | |
| Menu set | 1 Five-direction button | |
| Eelectrical | ||
| Power Supply | 12V DC ±25% | |
| Power Consumption | 22W | |
| Environmental | ||
| Operating Conditions | -30°C ~ 60°C (-22°F ~ 140°F) / Less than 95% RH * Start up should be done at above -30°C (-22°F) |
|
| Storage Conditions | -30°C ~ 60°C (-22°F ~ 140°F) / Less than 95% RH | |
| Ingress Protection & Vandal Resistance | IP67&IK10 | |
| Construction | ||
| Casing | Aluminium | |
| Dimensions | 286mm x 119mmx 106mm(11.26″×4.68″×4.19″) | |
| Net Weight | 2.05KG (4.5Ib) | |
| Gross Weight | 2.43KG (5.36Ib) | |
