Description
| Camera | ||
|---|---|---|
| Image Sensor | 1/2.8″STARVIS™ CMOS | |
| Effective Pixels | 1920(H) x 1080(V), 2 Megapixels | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | 1/3s~1/300,000s | |
| Min.Illumination | Color: 0.005Lux@F1.6; 0Lux@F1.6(IR on) | |
| S/N Ratio | More than 55dB | |
| IR Distance | Distance up to 150m (492ft) | |
| IR On/Off Control | Auto/Manual | |
| IR LEDs | 4 | |
| Lens | ||
| Focal Length | 4.8mm~120mm | |
| Max.Apertre | F1.6~F4.4 | |
| Angle of View | H: 59.2° ~ 2.4° | |
| Optical Zoom | 25x | |
| Focus Control | Auto/Manual | |
| Close Focus Distance | 100m~1000mm | |
| PTZ | ||
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°,auto flip 180° | |
| Manual Control Speed | Pan: 0.1° ~300° /s; Tilt: 0.1° ~200° /s | |
| Preset Speed | Pan: 400° /s; Tilt: 300° /s | |
| Presets | 300 | |
| PTZ Mode | 5 Pattern, 8 Tour, Auto Pan, Auto Scan | |
| Speed Setup | Human-oriented focal Length/speed adaptation | |
| Power Up Action | Auto restore to previous PTZ and lens status after power failure |
|
| Idle Motion | Activate Preset/Scan/Tour/Pattern if there is no command in the specified period |
|
| Protocol | DH-SD, Pelco-P/D (Auto recognition) | |
| Video | ||
| Resolution | 1080P(1920×1080)/720P(1280×720) | |
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P | |
| Video Output | 1-channel BNC HDCVI high definition video output/ CVBS standard definition video output (switchable) |
|
| Day/Night | Auto(ICR)/Color/B/W | |
| OSD Menu | Support | |
| Backlight Compensation | BLC/HLC/WDR(120dB) | |
| White Balance | Auto,ATW,Indoor,Outdoor,Manual | |
| Gain Control | Auto/Manual | |
| Noise Reduction | Ultra DNR (2D/3D) | |
| Digital Zoom | 16x | |
| Flip | 180° | |
| Privacy Masking | Up to 24 areas | |
| Certifications | ||
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB,ANSI C63.4- 2014 UL: UL60950-1 CAN/CSA C22.2,No.60950-1 |
|
| Interface | ||
| Video Interface | 1 | |
| Audio Interface | 1 channel In/Out | |
| RS485 | 1 | |
| Alarm | 2/1 | |
| Electrical | ||
| Power Supply | AC24V/3A (±10%)) | |
| Power Consumption | 13W, 23W (IR on) | |
| Environmental | ||
| Operating Conditions | -40°C ~ 70°C (-40°F ~ 158°F) / Less than 90% RH | |
| Ingress Protection | IP66 | |
| Vandal Resistance | N/A | |
| Construction | ||
| Casing | Metal | |
| Dimensions | Φ186.0(mm) x 309(mm) | |
| Net Weight | 3.5KG(7.72IB) | |
| Gross Weight | 6.8KG(14.99Ib) | |
[rt_button_style title=”CATALOG” link=”url:https://www.saxco.com.my/wp-content/uploads/2017/09/SD59225I-HC.pdf|||”]
