SpecificationsDownload
| System | ||
|---|---|---|
| Main Processor | Embedded Processor | |
| Operating System | Embedded LINUX | |
| Video and Audio | ||
| Analog Camera Input | 16 Channel, BNC | |
| HDCVI Camera | 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps | |
| AHD Camera | 4MP, 3MP, 1080P@25/30, 720P@25/30fps | |
| TVI Camera | 4MP, 1080P@25/30, 720P@25/30fps | |
| CVBS Camera | PAL/NTSC | |
| IP Camera Input | 16 8 Channel, each channel up to 5MP | |
| Audio In/Out | 1/1, RCA | |
| Two-way Talk | Reuse audio in/out, RCA | |
| Recording | ||
| Compression | H.265 /H.265/H.264 /H.264 | |
| Resolution | 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF | |
| Record Rate | Main stream | 4M-N/1080P(1~15fps);1080N/720P/960H/D1/CIF (1~25/30fps) |
| Sub stream | D1/CIF(1~15fps) | |
| Video Bit Rate | 32Kbps ~ 6144Kbps Per Channel | |
| Record Mode | Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop | |
| Record Interval | 1~60min (default: 60min), Pre-record:1~30 sec, Post~record:10~300 sec |
|
| Audio Compression | AAC(only for the 1st channel), G.711A, G.711U, PCM | |
| Audio Sample Rate | 8KHz, 16 bit Per Channel | |
| Audio Bit Rate | 64Kbps Per Channel | |
| Display | ||
| Interface | 1 HDMI, 1 VGA | |
| Resolution | 1920×1080, 1280×1024, 1280×720 | |
| Multi-screen Display | When IP extension mode not enabled: 1/4/8/9/16 When IP extension mode enabled:: 1/4/8/9/16/25 |
|
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |
| Network | ||
| Interface | 1 RJ-45 Port (1000M) | |
| Network Function | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Support Dahua IP camera, DVR, NVS, etc.) | |
| Max.User Access | 128 users | |
| Smart Phone | iPhone, iPad, Android | |
| Interoperability | ONVIF 16.12, CGI Conformant | |
| Video Detection and Alarm | ||
| Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips | |
| Video Detection | Motion Detection, MD Zones: 396 (22×18), Video Loss, Tampering and Diagnosis | |
| Alarm input | N/A | |
| Relay Output | N/A | |
| Playback and Backup | ||
| Playback | 1/4/9/16 | |
| Search Mode | Time/Date, Alarm, MD and Exact Search (accurate to second | |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
|
| Backup Mode | USB Device/Network | |
| Storage | ||
| Internal HDD | 2 SATA Ports, up to 10TB capacity for each disk | |
| eSATA | N/A | |
| Auxiliary Interface | ||
| USB | 1 USB 2.0 , 1 USB 3.0 | |
| RS232 | N/A | |
| RS485 | 1 Port, for PTZ Control | |
| Electrical | ||
| Power Supply | DC12V/4A | |
| Power Consumption(without HDD) | <15W | |
| Construction | ||
| Dimensions | 1U, 375mm×287mm×53mm (14.8″ x 11.3″ x 2.1″) | |
| Device with PFH101 Rack Mount Tray | 483mmx281mmx56mm (19.0″x11.1″x2.2″) | |
| Net Weight | 1.6kg (3.5 lb) (without HDD) | |
| Gross Weight | 3.0kg (6.6 lb) | |
| Installation | Desktop installation | |
| Environmental | ||
| Operating Conditions | -10°C ~ 55°C ( 14°F ~ 131°F), 10%~ 90% RH | |
| Storage Conditions | -20°C ~ 70°C (-4°F ~ 158°F) , 0~ 90% RH | |
| Certification | ||
| Certification | FCC | Part 15 Subpart B |
| CE: CE-LVD | EN 60950-1/IEC 60950-1 | |
| CE-EMC | EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 |
|
| UL | UL 60950-1 | |
