DH-IPC-HDBW4120FP : DAHUA 1.3MP HD NETWORK VANDAL-PROOF IR WEDGE DOME CAMERA

Model: DH-IPC-HDBW4120FP

and: Dahua

Description

Description

Camera
Image Sensor 1/3″ 1.3 Megapixel progressive scan SMOS
Effective Pixels 1280(H) x 960(V)
Scanning System Progressive
Electronic Shutter Speed Auto/Manual, 1/3(4)~1/100000s
Min.Illumination S/N Ratio
S/N Ratio More than 50dB
Video Output N/A
Camera Features
Max.IR LEDs Length 20m
Day/Night Auto(ICR)/Color/B/W
Backlight Compensation BLC/HLC/DWDR
White Balance Auto/Sunny/Night/Outdoor/Customized
Gain Control Noise Reduction
Noise Reduction 3D
Privacy Masking Up to 4 areas
Lens
Focal Length 3.6mm (2.8mm, 6mm optional)
Max Aperture F2.0(F1.8/F2.0)
Focus Control Manual
Angle of View 74°/86°/47°
Lens Type Fixed lens
Mount Type Board-in Type
Video
Compression H.264/H.264B/H.264H/MJPEG
Resolution 1.3M(1280×960)/720P(1280× 720)/ D1(704× 576/704× 480) /
CIF(352× 288/352× 240)
Frame Rate Main Stream 1.3M/720P(1 ~ 25/30fps)
Sub Stream D1/CIF(1 ~ 25/30fps)
Third Stream 720P(1-14/7fps)
Bit Rate H.264: 32K~10Mbps
Corridor Mode Support
Audio
Compression G.711a/G.711u/AAC(only for-AS)
Interface 1/1 channel In/Out (only for -AS)
Smart Function
Smart Detection Tripwire
Intrusion
Abandoned/Missing
Scene Change
Audio detect
Face detect
Network
Ethernet RJ-45 (10/100Base-T)
Wi-Fi N/A
Protocol IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP,
IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE,
DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x
Compatibility ONVIF, PSIA, CGI
Smart Phone iPhone, iPad, Android, Window Phone
Auxiliary Interface
Memory Slot Micro SD Max 128GB (only for -AS)
RS485 N/A
Alarm 1/1 channel In/Out (only for -AS)
PIR Sensor Range N/A
General
Power Supply DC12V, PoE (802.3af)
Power Consumption <5W
Working Environment -30°C~ 60°C, Less than 95% RH
Ingress Protection IP67
Vandal Resistance IK10
Dimensions Φ 106mm× 50.3mm
Weight 0.35KG
[rt_button_style title=”CATALOG” link=”url:https://www.saxco.com.my/wp-content/uploads/2017/08/DH-IPC-HDBW4120FP.pdf|||”]
