Description
| Camera | ||
|---|---|---|
| Image Sensor | 1/2.8″ 3 Megapixel progressive scan CMOS | |
| Effective Pixels | 2048(H)x1536(V) | |
| RAM/ROM | 1024MB/128MB | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | Auto/Manual, 1/3~1/100000s | |
| Minimum Illumination | 0.005Lux/F1.4 (Color,1/3s,30IRE) 0.03Lux/F1.4 (Color,1/30s,30IRE) 0Lux/F1.4(IR on) |
|
| S/N Ratio | More Than 50dB | |
| IR Distance | Distance up to 50m(164ft) | |
| IR On/Off Control | Auto/Manual | |
| IR LEDs | 3 | |
| Lens | ||
| Lens Type | Motorized/Auto Iris (Hall) | |
| Mount Type | Board-in | |
| Focal Length | 2.7~13.5mm motorized | |
| Max.Aperture | F1.4 | |
| Angle of View | H: 110 ˚~31 ˚ V:57 ˚ ~17 ˚ | |
| Optical Zoom | 5x | |
| Focus Control | Motorized | |
| Close Focus Distance | 0.3m (0.98ft) | |
| Pan/Tilt/Rotation | ||
| Pan/Tilt/Rotation Range | Pan:0˚~355˚; Tilt:0˚~65˚; Rotation:0˚~355˚ | |
| Intelligence | ||
| IVS | Tripwire, Intrusion, Object Abandoned/Missing | |
| Advanced Intelligent Functions | Face Detection, People Counting, Heat Map | |
| Video | ||
| Compression | H.265 /H.265/H.264 /H.264 | |
| Streaming Capability | 3 Streams | |
| Resolution | 3M(2048×1536)/ 1080P(1920×1080)/ 1.3M(1280×960)/ 720P(1280×720)/ D1(704×576/704×480)/ VGA(640×480)/ CIF(352×288/342×240) |
|
| Frame Rate | Main Stream: 3M(1~50/60fps) Sub Stream: D1 (1 ~ 50/60fps) Third Stream: 1080P(1~50/60fps) |
|
| Bit Rate Control | CBR/VBR | |
| Bit Rate | H.264: 24~10240Kbps H.265: 14~9216Kbps |
|
| Day/Night | Auto(ICR)/ Color/B/W | |
| BLC Mode | BLC/HLC/WDR(140dB)/SSA | |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual | |
| Gain Control | Auto/Manual | |
| Noise Reduction | 3D DNR | |
| Motion Detection | Off/ On (4 Zone, Rectangle) | |
| Region of Interest | Off/On (4 Zone) | |
| Electronic Image Stabilization (EIS) | Support | |
| Smart IR | Support | |
| Defog | Support | |
| Digital Zoom | 16x | |
| Flip | 0°/90°/180°/270° | |
| Mirror | Off/On | |
| Privacy Masking | Off/On (4 Area, Rectangle) | |
| Audio | ||
| Compression | G.711a/G.711Mu/AAC/ G.726 | |
| Network | ||
| Ethernet | RJ-45 (100/1000Base-T) | |
| Protocol | HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP; DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP; Bonjour;802.1x;Multicast;ICMP;IGMP;SNMP |
|
| Interoperability | ONVIF, PSIA, CGI | |
| Streaming Method | Unicast/Multicast | |
| Max.User Access | 10 Users/ 20 Users | |
| Edge Storage | Nas Local PC for instant recording Mirco SD card 128GB |
|
| Web Viewer | IE, Choreme, Firefox, Safari | |
| Management Software | Smart PSS, DSS, Easy4ip | |
| Smart Phone | IOS, Android | |
| Certification | ||
| Certifications | CE: (EN 60950:2000) UL: UL60950-1 FCC: FCC Part 15 Subpart B |
|
| Interface | ||
| Video Interface | 1 Port (For adjustment only) | |
| Audio Interface | 1/1 channel In/Out | |
| RS485 | N/A | |
| Alarm | 1 channel In: 5mA 5VDC 1 channel Out: 1A 30VDC/ 0.5A 50VAG |
|
| Electrical | ||
| Power Supply | DC12V, AC24V, PoE (802.3at)(Class 4) | |
| Power Consumption | <18W | |
| Environmental | ||
| Operating Conditions | -40° C ~ 60° C (-40° F ~ 140° F) / Less than 95% RH | |
| Storage Conditions | -40° C ~ 60° C (-40° F ~ 140° F) / Less than 95% RH | |
| Ingress Protection | IP67 | |
| Vandal Resistance | IK10 | |
| Construction | ||
| Casing | Metal | |
| Dimensions | Φ159.1mm×117.9mm(Φ6.26”×4.64”) | |
| Net Weight | 0.96KG (2.12Ib) | |
| Gross Weight | 1.75KG (3.56Ib) | |
[rt_button_style title=”CATALOG” link=”url:https://www.saxco.com.my/wp-content/uploads/2018/02/DH-IPC-HDBW8331E-Z_Datasheet_20170414.pdf|||”]
