Description
| SPECIFICATIONS | |
| CAMERA | |
| Image Sensor | 1/3 SONY CCD |
| Signal System | PAL/NTSC |
| Effective Pixels | 976 (H) × 494 (V) |
| Min. Illumination | 0.002 Lux @ (F1.4, AGC ON) 0.006 Lux @ (F2.5, AGC ON) |
| Shutter speed | PAL: 1/50s to 1/100,000s, NTSC: 1/60s to 1/100,000s |
| Lens | 3.7 mm, Angle of view: 70° (3.7 mm) |
| Lens Mount | M12 |
| Day & Night | Electronic |
| Horizontal Resolution | 700 TVL |
| Synchronization | Internal synchronization |
| Video Output | 1Vp-p composite output (75 Ω/BNC) |
| S/N Ratio | More than 62 dB |
| BLC | On |
| GENERAL | |
| Working Temperature/Humidity | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply | 12V DC ± 10% |
| Power Consumption | Max. 1W |
| Dimensions | 30×30×19mm |
| Weight | 200g (0.44lbs) |
[rt_button_style title=”download catalog” link=”url:https://www.aacgroup.com.my/uploads/product_pdf/DS-2CC51A2P-DG1.pdf|||”]
