Description
| Specifications | |
| CAMERA | |
| Image Sensor | 5MP CMOS Image Sensor |
| Effective Pixels | 2560 (H) × 1944 (V) |
| Min. Illumination | Color: 0.008 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter speed | PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
| Lens | 3.6 mm @ F1.2 |
| Horizontal Field of View | 70° (3.6 mm), |
| Lens Mount | M12 |
| Angle Adjustment | Pan: 0 – 360°, Tilt: 0 to 75°, Rotation: 0 – 360° |
| Day & Night | IR cut filter |
| Synchronization | Internal Synchronization |
| Video Frame Rate | 2560 × 1944 @ 20fps |
| MENU | |
| AGC | Support |
| Day / Night Mode | Auto/Color/BW (Black and White) |
| White Balance | ATW / MWB |
| BLC | Support |
| DWDR | Support |
| Language | English, Chinese |
| Functions | Brightness, Sharpness, Digital noise reduction, Mirror, Smart IR |
| Video Output | 1 HD analog output |
| GENERAL | |
| Working Temperature/Humidity | -40° C to 60° C (-22° F to 140° F) Humidity 90% or less (non-condensing) |
| Power Supply | 12V DC ±25% |
| Power Consumption | Max. 3.5W |
| Ingress Protection | IP67 |
| Material | Metal & Plastic |
| IR Range | Up to 40 meters |
| Communication | Up the coax, Protocol: HIKVISION-C(TVI output) |
| Dimensions | Φ 110 mm × 93.2 mm |
| Weight | 350g |
[rt_button_style title=”download catalog” link=”url:https://www.aacgroup.com.my/uploads/product_pdf/DS-2CE56H5T-IT3.pdf|||”]
