Description
| Specifications | |
| CAMERA | |
| Image Sensor | 8.29 megapixel progressive scan CMOS |
| Signal System | PAL/NTSC |
| Frame Rate | PAL: 8 MP@12.5fps, 5 MP@20fps, 4 MP@25fps, 1080p@25fps |
| Resolution | 3840 (H) × 2160 (V) |
| Min. Illumination | Color: 0.003 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter speed | PAL: 1/12.5 s to 1/10,000 s NTSC: 1/15 s to 1/10,000 s |
| Slow Shutter | Max. 16 times |
| Lens | 2.8 mm to 12 mm motorized vari-focal lens |
| Horizontal Field of View | 108.1° to 45.6° |
| Lens Mount | Φ14 |
| WDR | 120dB |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 355°, Tilt:0° to 75°, Rotate: 0° to 355° |
| Synchronization | Internal Synchronization |
| WDR | 120dB |
| MENU | |
| AGC | Support |
| Day / Night Mode | Auto/Color/BW (Black and White) |
| White Balance | Auto/Manual/Natural |
| Privacy Mask | ON/OFF, 4 programmable privacy masks |
| BLC | Support |
| 3D DNR | Level 1 to 10 |
| Language | English |
| Functions | Contrast, Sharpness, Saturation, Mirror, Defog, HLC |
| TVI Video Output | 1 HD analog output |
| CVBS Video Output | 1 CVBS output (75Ω/BNC) |
| GENERAL | |
| Working Temperature/Humidity | -40° C to 60° C (-22° F to 140° F) Humidity 90% or less (non-condensing) |
| Power Supply | 12 VDC ±25% -A: 12 VDC ±25%, 24 VDC ±25% |
| Power Consumption | Max. 9 W -A: Max. 10.5 W |
| Protection Level | IP67, IK10 |
| Material | Metal |
| IR Range | Up to 60 m |
| Communication | Up the coax, Protocol: HIKVISION-C(TVI output) |
| Dimensions | Φ 145.2 mm × 124.1 mm |
| Weight | 645g |
