Description
| SPECIFICATIONS | |
| VIDEO / AUDIO INPUT | |
| Video compression | H.265 /H.265/H.264 /H.264 |
| Analog and HD-TVI video input | 24CH, BNC interface (1.0Vp-p, 75 Ω), supporting coaxitron connection |
| HDTVI input | 5 MP, 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60 |
| AHD input | 5 MP, 4 MP, 720p25, 720p30, 1080p25, 1080p30 |
| HDCVI input | 1080p25, 1080p30, 720p25, 720p30 |
| CVBS input | Support |
| IP video input | 8-ch, (up to 32-ch), 8MP resolution |
| Supports H.265 /H.265/H.264 /H.264 IP cameras | |
| Audio compression | G.711u |
| Audio input | 4-ch, RCA (2.0 Vp-p, 1 KΩ)) |
| VIDEO / AUDIO OUTPUT | |
| CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI / VGA output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| HDMI2 output | 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Ecoding resolution | 5MP/ 4MP/ 3MP/ 1080p/ 720p/ WD1/ 4CIF/ VGA/ CIF |
| Frame rate | Main stream: 5 MP@12fps; 4 MP@ 15fps; 3 MP@18fps; 1080p/ 720p/ WD1/ 4CIF/ VGA/ CIF@25fps (P)/ 30fps (N) |
| Sub-stream: WD1/ 4CIF/ CIF@25fps (P)/ 30fps (N) |
|
| Video bitrate | 32kbps to 10Mbps |
| Audio output | 1-ch, RCA(Linear, 1KΩ) |
| Audio bitrate | 64kbps |
| Dual stream | Support |
| Stream type | Video, Video & Audio |
| Synchronous playback | 16-ch |
| NETWORK MANAGEMENT | |
| Remote connections | 128 |
| Network protocols | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| HARD DISK | |
| SATA | 4 SATA interfaces |
| eSATA | Support |
| Capacity | Up to 8TB capacity for each disk |
| EXTERNAL INTERFACE | |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (independent) |
| Network interface | 2, RJ45 10M/100M/1000M self-adaptive Ethernet interface |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (independent) |
| Serial interface | RS-232, RS-485 (full-duplex), Keyboard |
| USB port | Front panel: 2 × USB 2.0 Rear panel: 1 × USB 3.0 |
| Alarm in/out | 16 / 4 |
| GENERAL | |
| Power supply | 100 ~ 240VAC, 47 ~ 63Hz |
| Consumption (without hard disks) | ≤ 74W |
| Working temperature | -10 ºC ~ 55 ºC (14 ºF ~ 131 ºF) |
| Working humidity | 10% ~ 90% |
| Dimensions (W × D × H) | 445 x 390 x 70mm |
| Weight (without hard disks) | ≤ 7Kg (15.4lb) |
