Description
| Specifications | |
| CAMERA | |
| Image Sensor | 1/4-inches Progressive Scan CMOS |
| Min. illumination | 0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR 0.028Lux @ (F2.0, AGC ON) ,0 Lux with IR |
| Shutter time | 1/3 s to 1/100,000s |
| Lens | 4 mm @ F2.0 Angle of view: 55° |
| Lens mount | M12 |
| Day & night | IR cut filter with auto switch |
| Digital noise reduction | 3D Digital Noise Reduction |
| Wide dynamic range | Digital WDR |
| COMPRESSION STANDARD | |
| Video compression | H.264 / MJPEG |
| H.264 Type | Main Profile |
| Bit rate | 32 Kbps – 8 Mbps |
| Dual Stream | Yes |
| Audio Compression | G.711/G.722.1/G.726/MP2L2 |
| Audio Bit rate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| IMAGE | |
| Max. Image Resolution | 1280 x 720 |
| Frame rate | 50 Hz: 25 fps (1280 x 720), 25 fps (704 x 576), 25 fps (640 x 480) |
| Image settings | Rotate mode,Saturation, brightness, contrast, sharpeness adjustable through client software or web browser |
| Backlight Compensation | Yes, zone optional |
| ROI | Support |
| NETWORK | |
| Network storage | Local storage: Built-in Micro SD/SDHC/SDXC card slot, up to 128 GB. NAS (Support NFS,SMB/CIFS) |
| Alarm trigger | Intrusion detection, Line crossing detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General | One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
| System compatibility | ONVIF, PSIA, CGI, ISAPI |
| INTERFACE | |
| Communication interface | 1 RJ45 10M / 100M ethernet port |
| Alarm Input | 1 |
| Alarm Output | 1 |
| WIFI SPECIFICATIONS | |
| Wireless Standard | IEEE802.11b/g/n |
| Frequency Range | 2.4GHz – 2.4835GHz |
| Channel Bandwidth | 20/40MHz Support |
| Porotocols | 802.11b: CCK, QPSK, BPSK; 802.11b/n: OFDM |
| Security | 64/128bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmit Output Power | 11b: 17±1.5dBm @ 11Mbps 11g: 14±1.5dB @ 54Mbps 11n: 12.5±1.5dB |
| Receive Sensitiviy | 11b: -90dBm @ 11Mbps (Typical) 11g: -75dBm @ 54Mbps (Trypical) 11n: -74dBm (Trypical) |
| Transfer Rates | 11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps |
| Wireless Range | 50m(depend on environment) |
| GENERAL | |
| Operating conditions | -30 °C ~ 60 °C (-22°F ~ 140 °F) humidity 95% or less (non-condensing) |
| Power supply | 12 VDC ± 10% , PoE (802.3af)± 10% |
| Power consumption | Max. 5.5W |
| PIR | Angle: 80° Range: 10m |
| IR range | 10 meters |
| Dimensions (mm) | 72.3×89.9×131.3mm |
| Weight | 400g(0.88lbs) |
[rt_button_style title=”download catalog” link=”url:https://www.aacgroup.com.my/uploads/product_pdf/DS-2CD2410F-IW.pdf|||”]
