Description
| Specifications | |
| VIDEO / AUDIO INPUT | |
| IP video input | 16CH |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| NETWORK | |
| Incoming bandwidth | 160Mbps |
| Outgoing bandwidth | 80Mbps |
| Remote connection | 128 |
| VIDEO / AUDIO OUTPUT | |
| Decoding resolution | 6MP / 5MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Frame rate | Main stream: 50 fps (P) / 60 fps (N) Sub-stream: 50 fps (P) / 60 fps (N) |
| HDMI/VGA output | 1-ch, resolution: 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Audio output | 1-ch, RCA (Linear, 1kΩ) |
| DECODING | |
| Live / Playback resolution | 6MP / 5MP / 3MP / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Synchronous playback | 16-ch@4CIF, 12-ch@720P, 6-ch@1080P |
| HARD DISK | |
| SATA | 4 SATA interfaces for 2 HDDs 1 DVD-R/W (default), or 4HDDs |
| eSATA (Optional) | 1 eSATA interface |
| Capacity | Up to 4TB for each disk |
| EXTERNAL INTERFACE | |
| Network interface | 2 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces (1 for /P model) |
| Serial interface | RS-232 and RS-485 |
| USB interface | 2 × USB 2.0 1 × USB 3.0 |
| Alarm in/out (Optional) | 16 / 4 (optionally can be expanded to 16 / 8) |
| OTHERS | |
| Power supply | 100 ~ 240VAC |
| Consumption | ≤ 20W |
| Working temperature | -10 ºC ~ 55 ºC ( 14 ºF~ 131 ºF) |
| Working humidity | 10 % ~ 90 % |
| Chassis | 19-inch rack-mounted 1.5U chassis |
| Dimensions | 445 × 390 ×70 mm ( 17.5”× 15.3” × 2.8”) |
| Weight | ≤ 4 Kg (8.82 lb) |
